ACCSOON CineView Master 4K Lite Wireless Video Transmission System

Key Features

RX:

• HDMI and 3G-SDI video outputs

• Supports up to 4K60 video output

• Ultra-low latency transmission (as low as 35ms)

• Up to 350m / 1200ft wireless range

• Dual-band 2.4GHz + 5GHz wireless transmission

• Compatible with NP-F series batteries

TX:

• HDMI and 3G-SDI video inputs

• Supports 4K UHD 60fps wireless transmission

• HDMI loop-out and USB-C video output

• Camera control via USB-C connection

• Transmits to up to 4 receivers/mobile devices simultaneously

• Dual-band Wi-Fi 6 transmission technology

Specifications

Brand: ACCSOON
Model: CineView Master 4K Lite (WIT09)
Transmission Technology: Accsoon RTMS 4.0
Wireless Frequency: 2.4GHz + 5GHz
Maximum Range: 350m / 1200ft (line-of-sight)
Operating Temperature: -10°C to 40°C
DC Input: 7.4V–16.8V
Battery Type: NP-F550 / NP-F750 / NP-F970

RX:
Video Output: HDMI, 3G-SDI, USB Video Out
HDMI Output Resolution: Up to 4K60
Audio: HDMI & SDI Embedded
Power Consumption: 4.6W
Weight: 320g
Transmission Range: Up to 350m / 1148ft

TX:
Video Input: HDMI, 3G-SDI
Video Output: HDMI Loop-Out, USB Video Out
Camera Control: USB-C
HDMI Input Resolution: Up to DCI/UHD 4K60
Latency: <35ms (1080p60), <65ms (4K60)
Power Consumption: 4.6W
Weight: 322g

What's in the box?

TX + RX Set

• 1x Transmitter (TX)

• 1x Receiver (RX)

• 2x Cloud Platform

Receiver Only

• 1x Receiver (RX)
• 1x Cloud Platform

Transmitter Only

• 1x Transmitter (TX)

• 1x Cloud Platform
