TP-Link MC211CS-2 Omada Gigabit WDM Media Converter

Description:

• 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX
• Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
• Adopts WDM technology, transmitting and receiving data on one single fiber
• Extends fiber distance up to 2km

Specifications:

• Brand: TP-Link
• Model(s): TL-FC311A-2
• Standards and Protocols: IEEE 802.3i, 802.3u, 802.3ab, 802.3z
• Interface: 1× Gigabit SC Fiber Port / 1× 10/100/1000 Mbps RJ45 Port (Auto MDI/MDIX)
• Network Media: Single-mode Fiber / UTP category 5, 5e cable (maximum 100m)
• LED: PWR, Link/Act
• Connector: 1 SC Fiber Optic; 1 RJ45 jack
• Twisted Pair: 100BASE-Tx: 2-Pair UTP/STP of Cat. 5 or above (<- 100m) / 100BASE-Tx: 4-Pair UTP/STP of Cat. 5e or above (<-100m)
• Fiber: 9/125 μm single-mode fiber
• Transmission: TL-FC311A-2: <-2km
• Wave Length: TL-FC311A-2: 1550 nm Tx, 1310 nm Rx
• Power: External Power Adapter: 5 V/0.6A

What's in the Box:
• Gigabit Media Converter • Power Adapter • Installation Guide
